Godex ZX1600i Industrial Printer
4" Wide 600 DPI
A compact 600 DPI Industrial Printer. The Rise of Automation, ZX1000i+ is the Selection.
Description:
The Rise of Automation, ZX1000i+ is the Selection.
The ZX1000i+ series is equipped with an effective and robust print mechanism, designed and built for high-volume industrial printing jobs, and suitable for any segment in the production chain.
Features:
- 600 DPI Resolution
- All-Metal Frame Structure
- User-Friendly Interface
- Multiple Interfaces for Maximum Connectivity
- Various Output Options
- Supports High-volume Printing Jobs
- Easy Maintenance
- Full Range Adjustable Media Sensors
Specifications:
Print Method: | Thermal Transfer / Direct Thermal |
Resolution: | 600 dpi (24 dots/mm) |
Print Speed: | Up to 4 IPS (102 mm/s) |
Print Width: | 4.09” (104 mm, up to 105.6mm) |
Print Length: | Min. 0.16” (4 mm) Max. 31.5” (800 mm) |
Processor: | 32 Bit RISC CPU |
Memory: | Flash 256 MB SDRAM 256 MB |
Interfaces: | • USB 2.0 (Type B) • Serial Port (RS232) • Ethernet 10/100 Mbps • 3 USB Host (Type A). 2 ports at the front panel, 1 port at the rear panel |
Ribbon: | • Length Max. 1476’ (450 m) • Width Min. 1.18” (30 mm) – Max. 4.33” (110 mm) • Ribbon roll diameter 3” (76.2 mm) • Core diameter 1” (25.4 mm) |
Control Panel: | • Backlight 3.2” touch screen LCD • 1 Power on/off button with green colour LED backlight • 1 Control key: FEED/PAUSE/CANCEL with dual colour LED backlight: Ready(Green); Error(Red) • 1 Calibration button at rear panel |
